Model：WX-PCR16
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1.Application ofsingle-channel 16-hole African swine fever detector
Single-channel 16-hole African swine fever detector, also known as African swine fever PCR detector, African swine fever detector, single-channel 16-hole African swine fever detector, is used to run virus detection experiments, with corresponding reagents, to test samples taken from the samples to be tested Rapid and accurate qualitative detection of target nucleic acids in analytes or other analytes.
African swine fever virus detection is an important measure for the prevention and control of African swine fever and is of great significance.In order to further improve the accuracy of African swine fever virus detection results and standardize the production, operation and use of African swine fever virus diagnostic products, starting from January 1, 2021, all relevant departments and units will conduct animal quarantine or disease monitoring and diagnosis. When testing pigs and their products for African swine fever virus, diagnostic products for African swine fever virus that have obtained a product approval number issued by the Ministry of Agriculture and Rural Affairs should be used to ensure accurate test results.
The Vientiane African Swine Fever PCR Detector (real-time fluorescence quantitative PCR instrument supports variable temperature detection) is used to run virus detection experiments and analyze experimental data; the instrument can be operated in the laboratory or used in field scientific experiments with corresponding reagents , perform rapid and accurate qualitative detection of target nucleic acids in analytes or other analytes taken from samples to be detected.
The Vientiane African swine fever detector is equipped with the African swine fever virus fluorescent PCR detection kit and the African swine fever virus fluorescent PCR nucleic acid detection kit, which have been approved by the Ministry of Agriculture and Rural Affairs as products, which can meet the needs of rapid on-site detection of African swine fever nucleic acid.It can quantitatively and quickly diagnose livestock diseases such as African swine fever, swine fever, blue ear, pseudorabies and other diseases. It is widely used in farms, slaughterhouses, food processing plants, meat product deep processing enterprises, Ministry of Agriculture and Rural Affairs, Animal Husbandry Bureau, inspection Used by quarantine units.
Laboratory technicians need to undergo specialized training in laboratory technology, instrument and software operation, and have proficiency in relevant operating skills.
2. Instrument characteristics
1. Small size, light weight, easy to carry.Easily meet the needs of out-of-town experiments.
2. Built-in 10-inch high-definition capacitive screen PDA, touch screen operation, easy and fast.
3. Marlow's high-quality Peltier refrigeration chip, combined with the German high-end PT1000 temperature sensor and the temperature control mode of the electrical resistance heating compensation edge, has a maximum heating speed of 7°C and a maximum cooling speed of 5°C, which greatly shortens the experimental time.
4. 3s fast lighting mode for the entire board to ensure the consistency of hole positions in experimental results.
5. Simple and intuitive software guidance makes it easy to start detection experiments.
3. Application fields of African swine fever PCR detector
□ Basic scientific research
□ Pathogen detection
□ Adulteration of meat products
□ Transgenic detection
□ Food safety testing
□ Drug development and rational use of drugs
□ Gene expression
□ Water body monitoring
4. Technical parameters
Sample capacity: 16x0.2ml, supports 8 strips
Applicable consumables: common transparent PCR consumables, 8x0.2ml tubes, 0.2ml single tube
Reaction system: 5-120ul reaction mode system
Heating/cooling module: imported semiconductor thermoelectric module
Temperature control range: 4°C-99°C
The average rate of temperature rise and fall is ≥2°C/second
Temperature control accuracy: ≤±0.1°C
Temperature uniformity: ≤± 0.2°C
Number of temperature control areas: multiple points (2 points)
Number of gradients: 0
Gradient temperature range: None
Number of gradient holes: None
Excitation light source: maintenance-free LED
Excitation light wavelength range: 400-700nm
Detection components: imported photoelectric detector
Number of detection channels: standard 1 channel (FAM), advanced configuration (optional) (FAM, VIC)
Applicable dyes and probes: FAM/SYBR Green I, VIC/HEX/CY3 (optional), ROX/Texas Red (optional), Cy5, TAMARA (optional)
Software function: Fluorescent quantitative PCR system software;
Real-time amplification reaction curve function;
Real-time response curve display of specific specimens;
Data analysis functions;
Automatic judgment function of yin and yang results;
Graphical display function.
Noise: <45 dB
Screen size: 10 inches (HD)
Touch screen: capacitive
External USB: supports data import and export
Hot lid: automatic pressure adjustment
Appearance size: 290(W)*308(L)*130(H)
Box size: 75 long * 38 wide * 19 high cm
Net weight: about 3Kg
