Model：WX-SMLD2
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
The radar life detector can be used for life detection in free space and penetrating non-metallic media. It is mainly used to detect and search for human survivors buried in collapsed buildings, ruins, soil, or in environments such as smoke and fog.
1. General Requirements
1.1 Meets the requirements of the standard "Firefighting Radar Life Detector" (XF 3010-2020) *
1.2 For life detection in free space and through non-metallic media, it is mainly used to detect human survivors who are buried in collapsed buildings, ruins, soil, etc., or to search for human life in environments such as smoke and fog. *
2. Parameter performance requirements
1. Detection type: with two-dimensional positioning detection function, with two-dimensional positioning detection function, can display the detection target results on the screen in the form of coordinates. ▲
2. Detection range: After penetrating a 50cm thick brick wall, it can detect static living targets ≥26m away and moving targets ≥36m away.
3. The detection display: automatically identify whether there is a living body in the detection area, and display the detected static targets and moving targets with different graphics.
4. Detection of the angle of the sector: ≥120°. ▲
5. Remote control distance: The wireless communication distance between the radar host and the control terminal in an open environment ≥ 150 meters. ▲
6. The detector is equipped with multi-target detection function, which can detect the motion and vital signs such as breathing of ≥3 living bodies simultaneously, and display the function on the display control terminal.
7. Detection accuracy: Radar detection accuracy ≥ 95%
8. Pattern Selection: Search patterns can be selected for scenarios such as air, ruins, and wall penetration to achieve optimized detection.
9. Rechargeable battery: The battery life is not less than 12 hours with a single battery, and 2 batteries are equipped.
10. Working temperature: -20℃--+60℃.
11. Radar host (with battery) weight ≤ 7.7 kg. ▲
12. Protection level ≥ IP67. ▲
13. The control panel terminal screen of the detector is ≥ 8 inches, and the data collected by the device can be viewed in real time. ▲
Three, Other Requirements
1. Provide a third-party inspection report recognized by the state at the provincial level (including) or above at the time of bidding (the inspection report has the CMA or CNAS mark), and the inspection report reflects the technical indicators of the items marked with "▲" above.
