Model：WX-2DA
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
The radar life detector can obtain video information in real time, thus understanding the rescue information of the trapped personnel, observing the environment in which the trapped personnel are, and also saving or viewing the video to facilitate the detailed screening of information by the rescue team or the rescue assessment of the site environment.
1. Features and Functions:
1. Radar function: integrates millimeter wave radar technology and biomedical engineering technology, enabling it to have the ability to sense through walls (non-metallic building materials).
2. Video function: Real-time video information can be obtained to understand the distress signal of the trapped person, observe the environment where the trapped person is located, and the video can also be saved or viewed for detailed screening of information by the rescue team or rescue assessment of the site environment.
3. Audio function: Equipped with a high-sensitivity audio detector, it can monitor the distress signals sent out by the trapped person, thus cooperating in the rescue work.
4、Snake pipe design: The trapped people are often in a narrow space, and it is difficult for large equipment to reach. However, the snake pipe can be inserted into small cracks and has a certain degree of bending operability, so it can maximize the reach of the trapped person's position, thus obtaining more accurate information.
5、Hydraulic spreading: It can be directly used to rescue people trapped in a crowd, and it can also be used when a snake pipe cannot be inserted into a gap.
6、The system supports Chinese, Japanese, English, Korean, French and other languages.
Second, Product Parameters:
◆Implement the GB 4943.1-2022 "Information and Communication Technology Equipment Part 1";
◆Radar detection distance: ≤40 meters (varies due to differentobstructing environments)
◆Screen: 7-inch LCD screen
◆Video resolution: 1 million pixels
◆Memory: 32GB
◆Night vision: equipped with 6 pieces of 940 wave infrared lights (can't be seen by the naked eye)
◆Probe dimensions: length 62mm x width 24mm x thickness 12mm
◆Snake pipe length: 5 meters
◆Hydraulic spreader: Tonage---8T; Large opening distance---56mm
◆Working power supply: 5V voltage, built-in 5000mA lithium battery (about 10 hours of battery life);
◆ Carton size: 455mm x 340mm x 130mm
◆Product weight: 7kg (including aluminum box)
This product is a multi-functional rescue device that integrates advanced radar technology, high-sensitivity signal receiver, audio and video technology, and intelligent chips. It can be used to search for and rescue people who are trapped due to natural disasters. It can cope with complex environments such as narrow spaces, dark environments, and wall obstructions, and efficiently complete the search of the target area in one go. Moreover, the detector is lightweight, compact, and easy to operate. It can be equipped by a single soldier and is widely used in fire rescue, military reconnaissance, security inspection, and other tasks.
