Model：WX-FZ5
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1.Product introduction of color screen negative oxygen ion monitoring station
Color screen negative oxygen ion monitoring station, also known as natural oxygen bar monitoring station, environmental weather station, color screen negative oxygen ion monitoring station can monitor the concentration of negative oxygen ions in the air around the clock, and can expand monitoring projects according to user needs, and is widely used in tourist attractions and ecological estates , Wetland Park, Waterfall Park, Forest Park, Nature Reserve, Sales Office, School, etc.
The highly intelligent integrated negative oxygen ion monitoring station can monitor the concentration of negative oxygen ions in the air around the clock, and can expand monitoring items according to user needs, such as: air temperature, air humidity, PM2.5, PM10, atmospheric pressure, oxygen content, noise, Meteorological factors such as wind speed and direction. Integrated sensor design, no mechanical displacement, high precision and long service life
The data can be read on-site through the full-color LCD screen, or the data can be viewed in real time on the remote cloud platform/WEB/WeChat official account
On-site users can add customized songs, and can also perform voice broadcasts exceeding the standard.
2. Application scope
Tourist attractions, ecological estates, wetland parks, waterfall parks, forest parks, nature reserves, sales offices, schools
3. Technical parameters
1. Wind speed: measurement principle: ultrasonic, 0~60m/s (±0.1m/s) resolution 0.01m/s;
2. Wind direction: Measurement principle: ultrasonic, 0~360° (±2°) resolution 1°;
3. Air temperature: Measurement principle: diode junction voltage method, -40-60℃ (±0.3℃) resolution 0.01°; (Calibration certificate of Beijing Meteorological Bureau)
4. Air humidity: measurement principle capacitive, 0-100%RH (±0.3%RH) resolution 0.1%RH; (Beijing Meteorological Bureau calibration certificate)
5. Atmospheric pressure: Measurement principle: piezoresistive, 300-1100hpa (±0.25%), resolution 0.1hpa; (Calibration certificate of Beijing Meteorological Bureau)
6. PM2.5: Measurement principle: light scattering, 0-1000ug/m3 (±10%) resolution 1ug/m3
7. PM10: Measurement principle: light scattering, 0-1000ug/m3 (±10%) resolution 1ug/m3
8. Noise: Measurement principle capacitive, 30-120dB (±1.5dB) resolution 0.1db
9. Negative oxygen ions: Measurement principle: cylindrical electrode suction type, 0-100,000/m3 (±10%) resolution 1/m3
10. Oxygen content: measurement principle electrochemistry, 0~100%uol (±3%uol) resolution 0.1%
11. Screen: Resolution 1920 (RGB) × 1080 (FHD), operating frequency 120Hz, brightness 1500-2500 cd/m2
12. Pole: Carbon steel double column. Each column is made of two 1.5-meter pole flanges butt jointed together. It can withstand strong typhoons of level 15.
13. Working environment: temperature -40℃-65℃, humidity 0%-100%
14. Data storage: can store one year of original monitoring data
15. Data transmission: 4G/fiber optic
16. Power supply mode: 220V mains power
17. Power consumption: 500w
4. Product features
1. The whole machine adopts highly integrated modular design and standardized electrical design. The working status is clear at a glance and can achieve rapid maintenance.
2. Waterproof: The main structure is made of 2-3mm carbon steel, combined with composite sealing strips to achieve multi-angle waterproofing
3. Dustproof: The bottom of the equipment is equipped with a filtering device, which can filter dust particles above 5 μm. At the same time, the filter cotton can be quickly replaced from the outside without the need for professional operation.
4. Lightning protection and leakage protection: There are lightning protection devices and leakage protectors inside to protect the safety of the machine and surrounding people.
5. Made of high-transparency, high-temperature-resistant and high-strength tempered glass, fireproof, anti-scratch, and explosion-proof
6. Speaker: Outdoor high-power waterproof speaker, two-channel design, clear and three-dimensional sound
7. Built-in photosensitive probe, which can effectively identify changes in lighting and automatically adjust screen brightness.
8. The display screen uses LED backlight with a lifespan of 50,000 hours. It is environmentally friendly and energy-saving with high dynamic contrast and a clearer display.
9. The cooling system adopts industrial-grade eddy current centrifugal fans with large air volume, high speed and low noise. It has built-in temperature probe sensing equipment to effectively identify internal temperature changes. At the same time, the response temperature and response speed can be adjusted according to the on-site environment to achieve low energy consumption and accuracy. temperature control
10. Built-in time control switch, can set scheduled opening and closing time
11. Full-color display interface, the device automatically enters the weather monitoring platform when it is turned on (the display screen supports limited customization)
12. Optional camera, the display interface can synchronize the camera picture
13. Integrated sensor, integrated sensor, easy installation and simple maintenance
5. Product Structure Chart
6. Product size chart
7. Introduction to cloud platform
1. CS architecture software platform supports direct observation on mobile phones and PC browsers without the need to install additional software.
2. Support multiple accounts and multiple devices to log in
3. Support real-time data display and historical data display dashboard
4. Cloud servers and cloud data storage are stable and reliable, easy to expand, and load balanced.
5. Support SMS alarm and threshold setting
6. Support map display and view device information.
7. Support data curve analysis
8. Support data export table format
9. Support data forwarding, HJ-212 protocol, TCP forwarding, http protocol, etc.
10. Support data post-processing function
11. Support external running of javascript scripts
12. Support synchronized local weather forecast
