Model：WX-CZ5S
Product Price: Electronic Negotiation
Product brand: Wanxiang Environment
1、 Vehicle mounted weather station Product Introduction
The WX-CZ5S video based vehicle mounted weather station is a highly integrated, low-power, quickly installable, and easy to move monitoring high-precision automatic weather observation device.
Widely used in fields such as meteorology, agriculture and forestry, environmental protection, oceanography, airports, ports, scientific research, and campus education.
The device adopts a five element integrated sensor, which can observe meteorological elements such as wind speed, wind direction, air temperature, humidity, and atmospheric pressure in real time. The sensor housing is made of imported ABS material, which is more effective in combating salt spray and other environments, and the protection level reaches IP65 or above.
Built in 3 120 ° wide-angle cameras, paired with upper computer software, allowing real-time viewing of video images and monitoring data on the PC end.
Standard 485 to USB cable, can be connected to a laptop or pad to directly read data. Customers can randomly select one pad according to their own situation.
2、 Vehicle mounted weather station Product Features
1. Hidden ultrasonic probe on the top cover to avoid interference from accumulated rain and snow, and to prevent natural wind obstruction
2. The principle is to emit continuous variable frequency ultrasonic signals and detect wind speed by measuring relative phase
3. The bottom of the equipment is equipped with high-strength magnets (wrapped in rubber), which can be non destructively attached to the roof of the car
4. Shock absorption carrying case, convenient to carry
5. Built in electronic compass, automatically finds north
6. Dual mode positioning of Beidou and GPS, with a maximum accuracy of 0.1 meters
3、 Technical parameters
1. Wind speed: Ultrasonic principle, 0-60m/s (± 0.1m/s), can measure real wind speed
2. Wind direction: Ultrasonic principle, 0-360 ° (± 2 °)
3. Air temperature: Measurement principle - diode junction voltage method, -40-60 ℃ (± 0.3 ℃)
4. Air humidity: Measurement principle capacitive, 0-100% RH (± 3% RH)
5. Atmospheric pressure: Measurement principle pressure resistance type, 300-1100hPa (± 0.25%)
6. Data storage: no less than 500000 records
7. Camera: 3, 120 ° wide-angle, resolution 640 * 480
8. Power consumption: 3.12W
9. Lithium battery: capacity 12000mAh, battery life ≥ 24h
10. Total weight: ≤ 5kg
11. Deployment time: 1 person, no more than 2 minutes to complete the deployment
4、 Dimensional drawing
5、 PC interface display
6、 Introduction to upper computer software
1. PC standalone version data receiving, storage, viewing, and analysis software
2. Support serial data reception, processing, and display
3. Support communication methods such as JSON strings and Modbus 485
4. The storage time can be set by oneself, and the collection time can be set by oneself in modbus485 collection mode
5. Support self-service addition, deletion, and modification of monitoring parameters such as protocols, names, icons, etc
6. Support data post-processing function
7. Support external running of JavaScript scripts
